ACM 9 Communication Module
Connect as many as four ARE i9 read points to a production network through one compact communication module. ACM 9 supports EtherCAT, EtherNet/IP, PROFINET, and serial configurations, with LF and HF readers allowed on the same module.
- Up to 4 readers
- LF and HF together
- IP65
RFID-to-PLC Integration for Up to Four Read Points
ACM 9 sits between ARE i9 readers and the machine-control network. It supplies power and communication to the connected readers while consolidating their data through the selected industrial interface.
- Four reader connections — use one module for as many as four ARE i9 readers.
- Mixed-frequency systems — combine LF and HF reader heads on the same ACM 9 when the process uses more than one tag technology.
- Control-network choice — select EtherCAT, EtherNet/IP, PROFINET, or serial for the controls architecture already in place.
- Compact installation — a DIN-rail adapter is available for cabinet and machine integration.
- Simpler service replacement — the reader and communication layers remain separate, so a read point can be serviced without redesigning the network connection.
Built for Multi-Reader Machine Integration
Use one network endpoint to coordinate several compact RFID readers without locking every station to the same frequency.
- Multiplexed Connect up to four ARE i9 readers to one communication module.
- Protocol Choice Order the interface that matches EtherCAT, EtherNet/IP, PROFINET, or serial controls.
- Mixed LF + HF Combine low-frequency and high-frequency ARE i9 readers on one module.
- 24 V DC Fits the power architecture commonly used inside industrial machines and control cabinets.
- IP65 Housing Protected against dust and water jets when installed according to AEG ID requirements.
- DIN-Rail Option An available adapter provides a familiar mounting method for industrial enclosures.
ACM 9 Specifications
Pair ACM 9 with Readers and Industrial Tags
-
Stationary ReaderARE i9 Compact Reader
- LF/HF
- IP67
Extremely compact stationary reader that mounts directly on metal, no standoff bracket required. LF and HF variants.
View product → -
Production & LogisticsDisc Transponders
- LF/HF
- IP67
Flat disc transponder that mounts on boxes, pallets, carriers, and tooling in four sizes, from 13 mm to 50 mm, for production control and logistics in harsh environments.
View product → -
Keg & ContainerKeg Transponder
- LF
- IP67
ID 700 LF transponder optimized for direct mounting on stainless kegs and containers through a qualified micro-welded mounting ring.
View product →
Common ACM 9 Questions
-
How do you connect fixed RFID readers to a PLC?
Use an industrial RFID communication module between the reader heads and controller. ACM 9 supplies and coordinates up to four ARE i9 readers, then exposes their data through EtherCAT, EtherNet/IP, PROFINET, or serial communication for the machine controls.
-
How many ARE i9 readers can one ACM 9 support?
One ACM 9 supports up to four ARE i9 readers. The connected readers can be distributed across separate read points on the same machine or process.
-
Can LF and HF readers share one ACM 9?
Yes. AEG ID specifies that LF and HF ARE i9 readers can be mixed on the same ACM 9 communication module.
-
Which industrial network protocols are available?
ACM 9 is offered with EtherCAT, EtherNet/IP, PROFINET, or serial communication. Select the version that matches the machine controller or plant network.
-
Does ACM 9 read RFID tags by itself?
No. ACM 9 is the power, communication, and multiplexing layer. The connected ARE i9 reader heads create the RFID read points.
-
Is ACM 9 rated IP67?
No. AEG ID's current technical specification lists ACM 9 as IP65. The compatible ARE i9 reader is separately rated IP67 when its cable or dummy cap is installed correctly.
-
Can ACM 9 mount on DIN rail?
Yes. AEG ID lists a DIN-rail adapter as the mounting option for ACM 9. Confirm the adapter and interface version when configuring the order.
Integrating RFID into a Production Line?
Tell us the controls protocol, reader locations, tag technologies, and environmental requirements. UID will help scope the complete reader and communication layer.
